Heavy Duty Hydraulic Disc Brake

Construction Equipment Hydraulic Brake

FY60H

Hydraulic Brake

Hydraulic Brake
Hydraulic Brake
Request a Quote
FY60H Hydraulic Brake Technical Specifications
Model FY60H
Caliper Material High-strength Vermicular Graphite Cast Iron
Brake Type Normally Open, Hydraulic Brake
Pistons & Bore(mm) 6×75
Max. Oil Pressure (MPa) 14
Friction Coefficient 0.35
Pad Thickness (mm) 15
Max. Pad Wear (mm) 13
Brake Disc Thickness(mm) 18
Brake Disc Diameter(mm) 500
Effective Radius(mm) 207
Weight(kg) 40
Installation 3 o’clock or 9 o’clock position
Hydraulic Medium Mineral Oil or Synthetic Brake Fluid

Note: When the braking oil pressure exceeds 12.5 MPa, please contact our engineers for customized development services.

Fangyuan Industry is a premier high-tech manufacturer dedicated to the research, design, and mass production of high-performance braking systems. Since 1985, we have served as a critical OEM partner for global heavy-duty machinery leaders, providing essential stopping power for construction, mining, port logistics, and aerospace applications. Our products are engineered using high-strength alloy casting and precision CNC machining centers to ensure structural integrity under extreme stress.
