Hydraulic Braking Systems
G4C16A
Hydraulic Disc Brake
Request a
Quote
G4C16A Hydraulic Disc Brake Technical Specifications
| Model | G4C16A |
| Caliper Material | High-strength Ductile Iron |
| Brake Type | Floating Normally Closed |
| Mounting Angle | Any position |
| Adjustment Gap (mm) | 0.6-0.7 |
| Min. Release Pressure (MPa) | 6 |
| Full Retraction Pressure (MPa) | 10 |
| Lining Material / Static Friction Coeff. | Asbestos-free /≥0.5 |
| Friction Area per Set (CM2) | 116.6 |
| Friction Volume per Set (CM3) | 104.94 |
| Brake Disc Thickness (mm) | 12-18 |
| Disc Diameter Range (mm) | 260-700 |
| Displacement per Set (ml) | 8.5 |
| Allowable Wear per Side (mm) | 2 |
| Number of Pistons | 1 |
| Theoretical Braking Torque N·M | M=67.11*(D/2-35) (Initial) |
| M=35.78*(D/2-35) (Max. Wear) | |
| D-Brake Disc Diameter (mm) | |
| Total Weight(kg) | 17.56 |
