Heavy Duty Hydraulic Disc Brake

Construction Equipment Hydraulic Brake

FY-DP152.00

Disc Brake

Disc Brake
Disc Brake
Request a Quote
FY-DP152.00 Disc Brake Technical Specifications
Model FY-DP152.00
Caliper Material High-strength Ductile Iron
Brake Type Spring Applied, Hydraulic Released (SAHR)
Braking Torque ≥1200 N.m
Released Oil Pressure 2~5 MPa
Release Volume 11 cm3
Max. Rotation Speed(rpm) 300 rpm
Max. Working Temperature (℃) 85℃
Working Medium Hydraulic Oil
Weight 15 KG
rake Drum/Disc Diameter Range φ250~ φ600 mm
Brake Drum/Disc Width 45 mm

Note: Customized services and engineering support are available when the hydraulic medium or pressure requirements change.

Fangyuan Industry is a premier high-tech manufacturer dedicated to the research, design, and mass production of high-performance braking systems. Since 1985, we have served as a critical OEM partner for global heavy-duty machinery leaders, providing essential stopping power for construction, mining, port logistics, and aerospace applications. Our products are engineered using high-strength alloy casting and precision CNC machining centers to ensure structural integrity under extreme stress.
